Chassis & Wheelbase Selection
Every serious build starts with the right foundation. Select your vehicle platform and wheelbase so the planner can calculate payload, space and system recommendations more accurately.
1. Vehicle Platform
2. Wheelbase & Roof Variant
Disclaimer: Dimensions and weights are planning estimates. Confirm your actual vehicle measurements, VIN plate, V5C/specification data and weighbridge results before cutting, ordering or relying on payload calculations.
Module Registry1 / 14
Telemetry Status
Active Buildactive build
Mercedes-Benz Sprinter 144" WB Standard
144" WB Standard
estimated dataVehicle Dimensions
Exterior L/W/H5932 x 2020 x 2435 mm
Interior Load L/W/H3272 x 1787 x 1719 mm
Wheelbase3665 mm
hardware subtotal
£3950estimated build mass
2739kgBase Kerb: 2301kgGVW Limit: 3500kg
Est. Payload Remaining: 760.9546490000002kgStatus: Healthy
System Performance
Electrical Cap
100AhWater Storage
40LThermal Rating
3-Season StandardR-2.1
Est. Payload Remaining+761kg
Healthy payload margin
Axle Logic Hub
Front Axle Hub1563kg
Rear Axle Hub1177kg
